COM Express Type 6 – Computer-on-Modules
COM Express Type 6 Computer-on-Modules sind die ideale Wahl für die gesamte Bandbreite an Embedded-Computing-Anwendungen und sind in Ausführungen von energieeffizienten Prozessoren bis hin zu den neuesten Multicore-Technologien von Intel und AMD erhältlich.
COM Express Type 6 Computer-on-Modules sind die ideale Wahl für die gesamte Bandbreite an Embedded-Computing-Anwendungen und sind in Ausführungen von energieeffizienten Prozessoren bis hin zu den neuesten Multicore-Technologien von Intel und AMD erhältlich.
In zwei verschiedenen Formfaktoren bieten sie alles, was benötigt wird, um alles von leistungsstarken SPS, HMIs und Fertigungssystemen bis hin zu High-End-Digital-Signage-Systemen und hochleistungsfähiger Medizintechnik zu bauen.
COM Express® Compact Type 6
congatec conga-TCV2 - COM Express Compact Type 6 CPU-Modul COM Express Type 6 Compact module based on AMD Embedded Ryzen V2000 embedded processor series
